GR5 GRADER

The Grader GR5 is a durable, rugged, purpose-built machine capable of withstanding the most extreme conditions. By utilizing MacLean reliability, proven powertrain components, and valuable industry knowledge, the MacLean Grader ensures your road bed is smooth and consistent.

Category:

Benefits

  • Better operator ergonomics
  • Ease of maintenance with electronic engine diagnostics, accessible fuel filling and grease points
  • Six-wheel drive articulated carrier and hydrostatic transmission provide superior traction
  • Long life powertrain using proven components
  • Clean burning, fuel-efficient, high-powered, electronically controlled engine minimizes harmful emissions
  • Heavy-duty frame construction

Features

  • CANBUS control system
  • Enclosed, isolation-mounted, certified ROPS/FOPS cab
  • Control joysticks on armrests

Application

  • Fit-for-purpose machine for the underground environment

Specifications

GR5 Grader
Empty 44,000 lbs (20,000 kg)
Mercedes-Benz 906 Engine 210 hp (150 kW)
Width  2.28 m (90”)
Length  10.20 m (402″)
Tramming Height  2.54 m (100″)
Front Wheel Steering Angle  +/- 55°
Frame Articulation Angle  +/- 35°
Inside Turning Radius 2.54 m (100″)
Outside Turning Radius  6.60 m (260″)
